Past Inspection Findings

Piper Cherokee 6 rear spar corrosion
Continental O-200 piston
Cessna 170 gearbox corrosion
Lycoming O-320 exhaust guide crack
Cherokee 6 rear spar corrosion
Beechcraft bonanza wing corrosion due to mice
Crack inside Lycoming cylinder, no visible from exterior
Hole in a Mooney that was previously filled with body filler and painted over, not visible from exte
Piper Cherokee corrosion on inboard rib of flap
Lycoming O-360 crack in crankcase
Crack in exhaust muffler
Crack in engine mount on a Grumman Tiger
Cracked engine mount of Grumman Tiger
Wing corrosion due to rodents, Beechcraft Bonanza
Maule gear leg attach bolt holding on with just a thread
Cessna 170 gearbox corrosion
Cessna 170 gearbox corrosion

Key Factors

Corrosion

If looked over, corrosion can ruin an airplane faster than you will realize. Often looked over in hard to reach or see places, especially in older aircraft with spring steel landing gear. Rodents are another big red flag when it comers to corrosion, often if droppings or nesting material is found, best look close as urine corrodes aluminum extremely fast.

Engine Health

Engine health is usually easily made apparent by inspecting an oil filter for debris or sending out an oil analysis. BUT, these will not always tell the truth about an engines current state. Cylinder cracking and cam wear is easily noticed with a good magnifying glass, or with a good borescope inspection of the interior of an engine, the alternative to the old school "pulling a jug" to inspect the internals.

Exhaust Leaks

Known as "silent but deadly" carbon monoxide poisoning is no joke in reciprocating engines, as the heat from the exhaust is normally used to heat the cockpit of most single engine aircraft. Often looked over, mufflers, exhaust stacks and collectors often will crack due to vibration and should be dealt with immediately.

Logbooks & Aircraft Records

Aircraft logbooks, while essential to an airplane's monetary value, can also tell you almost everything about it. For example, was it is a flight school? Has it been damaged? Has it had a prop strike? Has maintenance been performed on time? Has it been actively flying or has it been sitting? Have the compressions been stable? All of which can be answered by a detailed inspection of the aircraft logbooks.
